BSIDE ACM91 Or ACM81 Mini Trms AC/DC Clamp Meter Low Impedance Low Current Available Auto Repair Clamp Type Multimeter

BSIDE ACM91 Or ACM81 Mini Trms AC/DC Clamp Meter Low Impedance Low Current Available Auto Repair Clamp Type Multimeter - Image 3

BSIDE ACM91 Or ACM81 Mini Trms AC/DC Clamp Meter Low Impedance Low Current Available Auto Repair Clamp Type Multimeter

Price range: 2,600.00৳ through 3,250.00৳

🔍 Product Description – ACM81 & ACM91 Digital Clamp Meter Series

🔔 Buzzer Alert Function – Audible buzzer triggers when resistance < 30Ω
🔗 Jaw Opening: 20mm – Suitable for compact wire measurements
🧪 Diode Test – Built-in on ACM81 (not available on ACM91) for quick semiconductor diagnostics
📈 True RMS Accuracy (TRMS) – Measures effective value across 45Hz–1kHz frequency range
📸 LCD Backlight & Data Hold – Easy viewing and freeze measurement readings for review
⏱️ Auto Power-Off – Conserves battery with shutdown after ~15 minutes of inactivity
⚡ NCV Detection (V~Alert) – Detects live AC voltage without direct contact
🔌 Live Wire Identification – Single probe detection available on ACM91 only
⚙️ Technical Highlights:

🔹 Input Impedance: 10MΩ
🔹 Sampling Rate: 3 times/sec
🔹 Under Voltage Prompt: Alerts below 24V
🔹 Overload Protection: Full-range protection up to 250

Add 3,000.00৳ to cart and get free shipping!

Varient

Clear

Add to wishlist

Description

On/off buzzer: The buzzer sounds when the measured resistance is less than 30 Ω

Tong head opening size: 20mm

Diode test: ACM81 has (ACM91 does not have this function)

TRMS true effective value: 45Hz~1kHz

Data retention: Yes

LCD backlight: Yes

Automatic shutdown: about 15 minutes without operation. Automatic shutdown NCV (non-contact voltage): V~Alert non-contact AC voltage detection indication

Live wire recognition: Single probe contact measurement identifies live wire (ACM91 only)

Input impedance: 10M Ω

Sampling rate: 3 times/second

Under voltage prompt: below 24V

Automatic protection: Full range overload protection below 250V

Specifications:
Display Type: Digital Only
DIY Supplies: Electrical
Measuring Resistance Range: 600-600 Mohm
Measuring Current Range: 6-100A
Measuring Voltage Range: 6-600V
Features: On/off buzzer, Tong head opening size 20mm, Diode test (ACM81 only), TRMS true effective value, Data retention, LCD backlight, Automatic shutdown, NCV (non-contact voltage), Live wire recognition (ACM91 only), Input impedance 10M Ω, Sampling rate 3 times/second, Under voltage prompt, Automatic protection

Features:
|Continuity Setting On Multimeter|Multimeter Diode Test|

**Precision Measurement and Safety**
The BSIDE ACM91 or ACM81 Mini Trms AC/DC Clamp Meter is a versatile tool designed for electrical professionals and DIY enthusiasts alike. With its digital-only display, this clamp meter offers clear and accurate readings for a range of electrical measurements, including resistance, current, and voltage. The clamp's 20mm opening size allows for easy access to conductors, while the TRMS true effective value ensures precise readings across a wide frequency range of 45Hz to 1kHz. The automatic shutdown feature conserves battery life, while the under voltage prompt keeps you informed of potential hazards.

**User-Friendly Design and Functionality**
The BSIDE clamp meter is not just about precision; it's also about user-friendly design and functionality. The on/off buzzer alerts you when the measured resistance is below 30 Ω, while the live wire recognition feature (ACM91 only) simplifies single probe contact measurements. The automatic protection system safeguards against overload, ensuring the device remains operational even in challenging environments. The NCV (non-contact voltage) detection and data retention capabilities make this clamp meter an indispensable tool for electrical troubleshooting and testing.

**Versatile Applications and User-Friendly Interface**
Whether you're testing continuity with a multimeter, using a multimeter to test an outlet, or performing diode tests, the BSIDE ACM91 or ACM81 Mini Trms AC/DC Clamp Meter is designed to meet your needs. The clamp's low impedance and low current capabilities make it suitable for a wide range of applications, from automotive repairs to home electrical maintenance. The user-friendly interface, with its backlit LCD and easy-to-use buttons, ensures that even novice users can operate the device with confidence. The clamp meter's compact size and lightweight design make it a convenient tool to carry around, ensuring that you have the right tool for the job at hand.

Additional information
