DC 3V-5V Metal Detector Electronic Parts DIY Kit Metal Detector Finder Non-contact Sensor Module

Original price was: 360.00৳ .Current price is: 319.00৳ .

⚙️ Product Specifications:

  • 🔋 Operating Voltage: DC 3V–5V
  • 📏 PCB Size: 92 × 60mm
  • ⚖️ Weight: Approx. 17g
  • 🎯 Detection Distance: ≤6cm (varies by object size and environment)
  • 🚨 Output Indicators:
    • Buzzer alert upon metal detection
    • LED illumination for visual feedback
  • 🛠️ Control: Adjustable sensitivity via 100Ω potentiometer (VR1)
  • 🔌 Power Input: USB male connector
  • 🧩 Assembly Required: Full component soldering, includes self-locking switch and passive components

Add 3,000.00৳  to cart and get free shipping!
Description

DC 3V-5V Metal Detector Electronic Parts DIY Kit Metal Detector Finder Non-contact Sensor Module

DIY Kit Metal Detector Kit Electronic Kit DC 3V-5V 60mm Non-contact Sensor Board Module DIY Electronic Parts Metal Detector

Ingredients list

No Name (EN) Format Amount
R1 Color ring resistance 200K 1
R2 Color ring resistance 2K 1
R3 Color ring resistance 470R 1
VR1 Adjustable resistance 100R 1
C1, C4 Ceramic capacitors 104P 2
C2 、 C3 Ceramic capacitors 222P 2
C5 Electrolytic capacitor 100μF 1
Q1 Transistor S9018 1
Q2, Q3 Transistor S9012 2
LED1 LED 5mm 1
SW1 The key 6P self-locking 1
SP2 Buzzer HSD9 * 12 1
Poweron USB male 1
—— PCB 1

Working voltage: 3~5V

PCB size: 92×60mm

Product weight: 17g

Measures:

1 List of components and comparing the number and properties of identity components

2 check the resistance of all resistors with a multimeter

3 Confirm the component polarity and mounting direction on the board in advance.

About debugging:

The machine is powered by 3 to 5V DC power. Turn on the power and turn on the power switch. At this time, the buzzer will sound.

When the LED is bright, slowly adjust the VR1 potentiometer so that the buzzer does not ring. Adjust the potentiometer to affect the detection distance. The detection distance of the machine is less than 6cm, which is affected by the size of the detected object and the environment.

Tools required for assembly testing:

Electric iron, solder wire, universal meter, tweezers, diagonal pliers, charging treasure
